The YXL Series is Yorkville Sound’s most affordable and versatile speaker lineup. Designed as an all-purpose speaker to be integrated into small and medium systems, YXL unpowered loudspeakers can be used vertically on the floor or a speaker stand, wedged as a stage monitor, or flown.
The YXL12 uses a single 12” driver and a 90° x 40° horn with a 1-inch throat and 1-inch compression driver. The cabinet is constructed with strong polypropylene for reliability and durability.
YXL delivers clear sound, exceptional value, and the best price-to-performance ratio of any Yorkville Sound PA series.
| System Type | Unpowered Loudspeaker |
| Power Rating | 1200 W Peak (600 W Program) |
| Nominal Impedance (Ohms) | 8Ω |
| Sensitivity (dB AT 1Watt/1m) | 97 dB |
| Max SPL | 122 dB Continuous |
| Frequency Response (Hz +/- 3dB) | 55 Hz - 16 kHz |
| Dispersion (H x V) | 90° x 40° |
| Crossover Frequency | 1.6 kHz |
| HF Driver(s) | 1” compression driver |
| HF Horn | Integrated into Baffle |
| LF Driver(s) | 12” with 2” Voice Coil |
| Inputs | 2x Speakon 2x 1/4" |
| Bar Handles | 2 (1x Side, 1x Back) |
| Flypoints | 2 (2x Top, 1x Pullback) |
| Flying Hardware | M8 Metric Threading |
| Pole Mount Adapter (1 3/8 | Dual Angle (1x Bottom) |
| Enclosure Materials | Polypropylene |
| Dimensions (DWH) | 13.5" x 14" x 23" (34 cm x 35.5 cm x 58.5 cm) |
| Weight | 38 lbs / 17.24 kg |
