The StudioLive 32SC is a compact, rack-mountable 32-channel digital mixer that can be quickly and easily scaled for 16-, 24-, and 32-channel applications. Don't let the road-ready size fool you; the StudioLive 32SC sports a dual-core PreSonus FLEX DSP Engine powering 40 mixing channels, 26 mix buses, and 286 simultaneous processorsincluding 4 stereo reverberation systems and Fat Channel plug-in models on every input channel and mix bus. With 128 (64x64) channels of USB recording and AVB network audio I/O, flexible routing options, and studio-grade audio quality, the StudioLive 32SC provides all the tools you needwhether you're building your dream studio or putting together a pro touring rig.
The Scalable Digital Mixer.
The StudioLive 32SC digital mixer and the complete PreSonus StudioLive Series III ecosystem of AVB networking products allow you to create a system that is truly customized for your needs. Connect NSB-series stage boxes to add remote analog inputs and outputs wherever they're required and complete your 32-channel, 16-bus StudioLive 32SC. Add EarMix 16M personal monitor mixers to give your musicians their own customizable 16-channel monitor mixes. Multiple StudioLive Series III digital mixers can be networked, allowing you to route audio to and from any device on the audio network thanks to the flexibility of Digital Patching on your StudioLive 32SC digital mixer and in UC Surface remote mixer software.
The Best Music Recording Software, Included!
Studio One revolutionized music recording, making common mixing and production tasks as easy as drag-and-drop. Tight integration with StudioLive 32SC digital mixers allows you to control preamp levels and more right from the Studio One software console. Press the DAW button on your StudioLive 32SC, and your Studio One controls are right under your fingertips on your digital mixer. Studio One control can be toggled on and off, allowing you to quickly switch between your live mix and your production mix with the press of a button. Studio One Artist is included with the StudioLive 32SC, so you can start recording right out of the box.
Remote Control Your Digital Mixer from Anywhere- On Any Device.
PreSonus StudioLive Series III digital mixers are tightly integrated with an entire suite of state-of-the-art software. Mix wirelessly using UC Surface touch-control software for macOS, Windows, iPad and Android. Control your monitor mixes with QMix-UC for iPhone, iPod touch, and Android devices. Whether you're adjusting monitor mixes on stage, moving around the room to dial in your mix, or using your mobile device as a second screen for your StudioLive 32SC digital mixer, remotely controlling your mix from anywhere just got easier.
The Digital Mixer Built to Record Music.
With 128 (64x64) channels of recording over USB, you can record every input channel and bus on your StudioLive 32SC for the ultimate recording rig. Each channel can independently access its analog input or its dedicated digital return from your computer. Ten vintage EQ and classic compressor Fat Channel plug-in models are included and can be used onboard your mixer, as well as within Studio One. When you're ready for more signal processing options, PreSonus offers four Fat Channel plug-in collections with 15 additional models. Fat Channel plug-ins can be inserted on every input channel and output bus, giving you extensive, studio-style processing while mixing and recording.
Includes Studio Magic Plug-in Suite.
This suite of plug-ins adds a wealth of fresh virtual instruments and effects to Studio One. Cherry-picked from the first names in virtual instruments and effects, each plug-in brings a different flavor of practical magic to your songs. These plug-ins aren't gimmicky one-trick ponies; these are real-deal workhorses that you'll rely on for countless mixes.
Features
• Powered by the new dual-core PreSonus FLEX DSP Engine to provide the most processing of any digital mixer in its class
• 40 input-channel digital mixer with 17 touch-sensitive motorized faders
• 26 mix buses
• 286 simultaneous processors
• State Space-Modeled Fat Channel compressor and EQ plug-ins available on every input channel and output bus
• FLEX FX multi-effects processor with 4 slots to load legendary reverb emulations and delays with 4 dedicated effects buses
• 128-channel (64x64) recording over USB
• Onboard multi-channel SD recorder (34x34) with true Virtual Soundcheck mode
• Remote control every mix function from your computer, iPad, or Android tablet with UC Surface
• Capture 3.0 multitrack software included
• Advanced Studio One integration (Studio One Artist Included)
Specifications
Microphone Preamplifier
Input Type: 16 x XLR Female, balanced
Frequency Response to Main Output (at unity gain): 20-20 kHz, +/-0.5 dBu
Input Impedance: 1 kΩ
Common Mode Rejection Ratio (1 kHz at unity gain): 65 dB
Gain Control Range (+/- 1 dB): 0 dB to +60 dB
Maximum Input Level (unity gain): +12 dBu
Phantom Power (+/-2 VDC): 48 VDC, switchable per channel
Line Inputs
Grade: 1/4" TRS Female, balanced
Frequency Response to Main Output (at unity gain): 20-20 kHz, 0.5 dBu
Input Impedance: 10 kΩ
Maximum Input Level: +18 dBu
Tape Inputs
Grade: RCA Female, unbalanced (stereo pair)
Maximum Input Level: +12 dBu, +/-0.5 dBu
XLR Outputs
Grade: XLR Male, balanced
Maximum Output Level: +24 dBu, +/-0.5 dBu
Output Impedance: 100Ω
Line Outputs
Grade: 1/4" TRS Female, balanced
Maximum Output Level: + 18 dBu, +/-0.5 dBu
Output Impedance: 100Ω
Tape Outputs
Grade: RCA Female, unbalanced (stereo pair)
Maximum Output Level: + 18 dBu, +/-0.5 dBu
Output Impedance: 100Ω
Headphone Output
Grade: 1/4" TRS Female, active stereo
Maximum Output: 100 mW / ch. @ 60Ω load
Frequency Response: 20 Hz - 20 kHz (+/-0.5 dB)
